High Performance 3 Heads Digital Printer
Siab -Kev Ua Haujlwm 3 Lub Taub Hau Digital Tshuab Luam Ntawv
Lub tshuab luam ntawv digital yog lub tshuab luam ntawv digital uas hloov cov ntaub ntawv hluav taws xob ncaj qha mus rau hauv lub cev luam tawm los ntawm kev tso tus number case los yog toner rau hauv cov substrates, tsis tas yuav tsum muaj cov kauj ruam nruab nrab xws li phaj ua lossis stencil creation.Nws yog dav siv thoob plaws hauv kev lag luam, nrog ob hom thev naus laus zis tseem ceeb: inkjet cov tshuab luam ntawv digital (siv cov tshuab luam ntawv microscopic rau cov tshuab luam ntawv cov tshuab luam ntawv. unparalleled yooj yooj yim thiab efficiency: lawv txhawb ib tug -daim ntawv luam ntawv (tsis muaj yam tsawg kawg nkaus txiav txim kom muaj nuj nqis), tiag tiag - sij hawm tsim kho, thiab sib txawv cov ntaub ntawv luam ntawv (VDP)- tso cai tshwj xeeb cov ntsiab lus xws li cov npe, QR code, los yog serial tooj ntxiv rau txhua luam ntawv. Lawv kuj tshem tawm cov nqi phaj thiab lub sijhawm teeb tsa, txo qis kev nqis peev thiab kev ua haujlwm pov tseg, ua rau lawv zoo tagnrho rau cov khoom me me, kev txiav txim siab, thiab cov phiaj xwm hloov pauv sai.
Technical Parameter Table
|
Qauv |
Lub taub hau luam ntawv (3 Pcs) |
Print daws teeb meem (dpi) |
Luam nrawm |
Xim Configuration |
Hom cwj mem |
Print Size Range |
Substrate Compatibility |
Lub zog (kw) |
Tshuab Dimensions (mm) |
Qhov hnyav (kg) |
Daim ntawv thov |
|---|---|---|---|---|---|---|---|---|---|---|---|
|
3HP-DP01 (Kev lag luam) |
Epson I3200-A1 |
1440 × 1440 (Max 2880 × 2880) |
9 ㎡ / h (6-pass); 7.5 ㎡ / h (8-pass); 35 ㎡ / h (4-pass rau textile) |
CMYK + Dawb + Varnish (yeem) |
UV-Curable / Dej-raws li / Dye Sublimation |
A4 rau 1800 × 1300mm |
Ntawv, Cardstock, Npuag, Yas, Nyias Acrylic, PET Film |
1.2 |
1850×900×1640 |
202 |
Cov khw luam ntawv me, DIY Studios, tshaj tawm, me me -Batch Textile Printing |
|
3HP-DP02 (Industrial Textile) |
Epson I3200-A1 |
1440 × 1440 (Max 3200) |
120 ㎡ / h (2-pass); 1500 mtr / 24 teev (44 ") |
CMYK + LC + LM |
Dye Sublimation Ink |
1900mm (Dav) × Unlimited (Length) |
Polyester, Chiffon, Silk, Chij, Textile Fabrics |
2.5 |
4400×2450×1250 |
650 |
Textile Mills, Fashion Factories, Loj -Sale Fabric Printing |
|
3HP -DP03 (Industrial UV) |
Ricoh G5i |
1440 × 1440 (Max 2880 × 2880) |
100 ㎡/h (xim); 200 ㎡/h (Hloov hom) |
CMYK + Dawb + Varnish + LC + LM |
UV-Curable Ink (LUS-120/LUS-350 Optional) |
A0 rau 2500 × 1300mm |
Iav, Hlau, Ceramic, Acrylic, Yas, Ntawv, Khoom siv hauv tsev |
3.5 |
1800×1200×1600 |
680 |
Ntim Factories, Muaj Kho Kom Zoo Nkauj, Loj -Txoj Kev Tshaj Tawm |
|
3HP-DP04 (DTF Kev Lag Luam) |
Epson XP600 |
720 × 1200 rau 720 × 2400 |
4 ㎡ / h (6-pass); 2.1 ㎡/h (8-pass); 1 ㎡ / h (12-pass) |
CMYK + Dawb + Fluorescent Xim (yeem) |
DTF Ink |
Tsawg dua lossis sib npaug li 600mm (Dav) × Unlimited (Length) |
PET zaj duab xis, Textiles, tsoos tsho, khoom plig Custom |
1.2 |
1700×750×1500 |
30 |
DTF Printing Shops, Custom Apparel, Small-Batch Gift Production |
|
3HP -DP05 (Kev cai) |
Customizable (Epson / Ricoh / Toshiba) |
Customizable (720 × 720 rau 2880 × 2880) |
Customizable (1 ㎡ / h txog 120 ㎡ / h) |
Customizable (CMYK, CMYK + W + V, CMYK + LC + LM) |
Customizable (UV-Curable/Dye Sublimation/Dej-Based/DTF) |
Customizable (A4 txog 3000 × 6000mm) |
Customizable (tag nrho cov substrates) |
1.2-4.0 |
Customizable (1700 × 750 × 1500 rau 2500 × 1500 × 1800) |
30-800 |
Tshwj xeeb Customization, Muaj Ntau Lawm, Siab -Precision Printing |
Core Zoo
Triple-Parallel Printing & Kev Kub Ceev
Peb lub taub hau luam ntawv ua haujlwm sib luag, ob npaug lossis peb npaug ntawm kev luam ntawv nrawm piv rau ib zaug - cov qauv taub hau (txog 120 ㎡ / h rau cov qauv kev lag luam textile). Qhov no txo qis cov voj voog ntau lawm, ua rau nws zoo tagnrho rau siab - ntim xaj thiab cov haujlwm ceev.
High Precision & Vibrant Xim
Nruab nrog kev lag luam - qib luam tawm lub taub hau thiab hloov pauv tus cwj mem poob tshuab, ua tiav cov kev daws teeb meem luam tawm mus txog 2880 dpi.Qhov triple - lub taub hau teeb tsa (CMYK + LC / LM lossis Dawb + Varnish) txhim kho xim gamut thiab txheej txheej, ua kom cov gradients du, meej meej, thiab cov qauv zoo sib xws, {6} xim repro.
Lub Sij Hawm Ntev -Lub Sijhawm Ua Haujlwm
Triple- lub taub hau tsim kom txo tau hnav ntawm txhua tus neeg lub taub hau, ncua kev pab cuam lub neej (txog 10,000 teev ib lub taub hau). Nruab nrog lub tshuab ntse ntse- ntxuav, moisturizing, thiab cov tshuab luam ntawv dawb, tiv thaiv kev txhaws thiab ua kom cov number case ruaj khov rau 24-teev kev ua haujlwm tas mus li. Tus nqi qis qis (tsawg dua lossis sib npaug li 0.3% txhua hli) txo qis sijhawm.
Wide Compatibility & Versatility
Txhawb ntau hom cwj mem (UV- kho tau, zas xim sublimation, dej-raws li, DTF) thiab ntau hom substrates- ntawm ntawv thiab ntaub rau cov ntaub ntawv nruj xws li iav thiab hlau. Adjustable fixtures thiab print beds haum qhov ntau thiab tsawg thiab thicknesses, expanding daim ntawv thov.
vim li cas xaiv peb
Siab -Cov Cheebtsam Zoo & Kev Ua Haujlwm ruaj khov:
Peb siv high -cov khoom tseem ceeb kawg (Epson I3200-A1, Ricoh G5i print heads, THK guide rails, Leadshine motors) tau los ntawm cov neeg muab kev ntseeg siab, ua kom ruaj khov thiab ua haujlwm zoo ib yam. Cov tshuab muaj lub neej ua haujlwm ntev (5-8 xyoos) thiab cov nqi kho mob qis, txo qis kev pheej hmoo ua haujlwm. Txhua lub tshuab raug kuaj thiab sim ua ntej xa khoom.
Customizable daws teeb meem:
Ib qho - ntawm - ib qho kev hloov kho raws li cov neeg siv khoom xav tau - hloov kho lub taub hau hom, tus cwj mem hom, kev daws teeb meem, nrawm, xim teeb tsa, thiab lub tshuab qhov ntev. Rau cov neeg siv khoom B2C, peb muab cov qauv kev lag luam compact; rau B2B cov neeg siv khoom, peb muab kev lag luam- cov qauv qib nrog cov kev xaiv sib xyaw ua ke (pub noj / tshem tawm tshuab). Customizable ink hom hloov mus rau tej substrates (xws li, DTF number case rau garments, UV number case rau cov ntaub ntawv nruj).
Ultra- Tsawg MOQ & Hoobkas- Tus nqi sib tw ncaj qha:
B2B thiab B2C cov neeg yuav khoom tau txais txiaj ntsig los ntawm ultra- MOQ qis (1 chav tsev rau txhua tus qauv), tso cai rau cov lag luam me thiab DIY studios los yuav yam tsis muaj siab ntau. Factory- tus nqi ncaj qha tshem tawm cov kev sib txuas nruab nrab, txo tus nqi yuav khoom los ntawm 20-30% piv rau cov neeg xa khoom. Ib txoj haujlwm muaj nuj nqis muaj rau kev koom tes mus ntev B2B.
Lub Sijhawm Lead Ceev & Kev Xa Khoom Thoob Ntiaj Teb:
Cov qauv qauv nkoj hauv 2-5 hnub ua haujlwm; Cov qauv kev cai muaj lub sijhawm ua haujlwm ntawm 7-15 hnub ua haujlwm [superscript:8]. Peb muab kev xa khoom thoob ntiaj teb mus rau txhua cheeb tsam loj. Cov qauv tsim tau raug xa los ntawm FedEx / DHL (3-7 hnub ua haujlwm), thaum cov qauv kev lag luam siv hiav txwv / tsheb thauj mus los kom txo nqi. Kev ntim khoom (ISPM 15 ua raws) zam kev thauj mus los.
Ntau yam khoom
Yog koj txaus siab rau qhov no3 Lub taub hau Digital tshuab luam ntawvlos yog lwm yam khoom lag luam, koj tuaj yeem tiv tauj peb txhua lub sijhawm, peb kuj muaj lwm cov khoom lag luam hauv kev lag luam lim khoom. Koj tuaj yeem nias hauv qab no kawm paub ntxiv txog nws.
Cim npe nrov: Tuam Tshoj 3 taub hau digital tshuab luam ntawv, Tuam Tshoj siab kev ua tau zoo 3 hau digital tshuab luam ntawv manufacturers, lwm tus neeg, Hoobkas
